Emarat 40 FT Mobile Fueling Unit.

40 FT dual-compartment mobile fueling unit for Emarat, Dubai, UAE. Project model MFU-3A. My role covered design leadership, project coordination and lead mechanical/package design, from tender to SAT.

42,600 L gross40,500 L safe fillDual compartmentUL 142 · UL 2085

Project Snapshot

CLIENT

Emarat · Dubai, UAE

Project for manufacture and supply of a 40 FT dual-compartment mobile fueling unit.

TANK

42,600 L gross

Safe fill capacity 40,500 L with dual-compartment construction.

ROLE

Head of Design · Project Coordinator · Lead Mechanical Designer

Involved from tender through design, procurement, manufacturing, FAT and SAT.

My Contribution

DESIGNED: Complete 3D model in SolidWorks and 2D engineering drawings in AutoCAD for the mobile fueling package and its mechanical interfaces.

COORDINATED: Procurement, production and instrumentation, plus the project interfaces, working to the Emarat requirements that applied to this unit.

LED: Design coordination as Head of Design Department, Project Coordinator and Lead Mechanical/Package Designer, including customer-facing technical coordination.

EXECUTED: Supported the project from tender submission and award through manufacturing, FAT and SAT.

Dimensions12,192 × 2,438 × ~2,896 mm

Tank walls6 mm inner · 6 mm outer

Fire guard75 mm insulation · 2 hours

Design pressure7 kPa

Tank & Fuel-System Architecture

03.1

Dual-Compartment Tank

42,600 L gross capacity with 40,500 L safe-fill capacity, 6 mm inner and outer walls and a 75 mm fire-guard insulation arrangement.

03.2

Pressure & Testing

Design pressure 7 kPa and leak pressure test 21 kPa. Weld coefficient 0.85; inspection and welding references included NB/T 47013 and NB/T 47015.

03.3

Fuel Connections

Package included 3 in fill, 1.5 in bowser, 2 in product delivery, 2 in drain, vapor-recovery connections and breather/emergency vent arrangements.

03.4

Fueling Equipment

Integrated dispenser, submersible turbine pump, ATG console/probe, overfill protection, interstitial leak sensing and associated fueling interfaces.

03.5

Safety Systems

Explosion-proof control panel/lighting, static earthing, emergency ventilation, interstitial and primary emergency venting, spill/drainage provisions and fire-safety equipment.

03.6

Standards / References

The drawing package references UL 142 and UL 2085 for tank design/build/test/certification, with ASME B16.5 Class 150 flanges and other project-specific inspection/welding requirements.

How the unit works

A 40 FT dual-compartment mobile fueling unit: bulk filling from a road tanker, double-wall storage with level and leak monitoring, and dispensing through a submersible turbine pump and dispenser.

The animation follows the fuel through the systems described above: fill point, overfill protection and vapour recovery, ATG and interstitial leak sensing, the 2 in product line to the dispenser, breather and emergency venting, and the safety systems around them.

Original illustrative animation · not a project drawing · component positions simplified. Use the step buttons to walk through it.

Meta Green — Portable Fueling Unit (PFU). Company product video published by Meta Green Middle East FZ-LLC on YouTube, showing the PFU design used for both this Emarat unit and the Maser demonstration unit (F-07). Capacities shown in the video cover the product range; this unit is 42,600 L gross.

Project Evidence

Photographs from commissioning and customer inspection, and inside the equipment cabinet: fill, vapor-recovery and drain connections, valve manifold and explosion-proof controls.

Emarat 40 FT mobile fueling unit during commissioning, team on the tank roof — **Commissioning**Unit on site during commissioning, team working on the tank top.

Customer representatives inspecting the green Emarat mobile fueling unit in the workshop — **Customer inspection**Client walk-round of the completed unit in the workshop.

Engineers and site team inspecting the dispensing cabinet of the Emarat unit — **Cabinet inspection**Technical review at the dispensing/equipment cabinet.

Fill point, vapor-recovery stage 1 and drain piping with cam-lock couplings and spill tray — **Fill, VR & drain points**Labelled fill, vapor-recovery and drain connections over the spill tray.

Product filling hose connected at the fill point inside the equipment cabinet — **Filling connection**Bulk filling hose on the fill point; manifold valves and ATG console above.

Valve manifold with explosion-proof control panels inside the equipment cabinet — **Manifold & Ex panels**Valve manifold, explosion-proof control stations and cam-lock outlets.

Client site visit

A delegation from Al Maha Petroleum Products Marketing Co. (Oman) at the Emarat station on this project, as part of the same visit as the F-07 demo unit walk-round.

Visiting delegation and project team outside the shop at an Emarat service station — **Site visit**Delegation and project team at the Emarat station on the F-01 project.

Visitors touring the shop of an Emarat service station with station staff — **Station tour**Walk-through of the station with the site team.

Evidence note: These are genuine project photographs. Controlled customer drawings, confidential employer documents and proprietary vendor information are not reproduced in this portfolio.

Engineering & Project Flow

Tender→Award→3D design→2D drawings→Procurement→Production→FAT→SAT

Engineering Takeaway

This job went well past CAD. I put together a mobile fuel storage and dispensing system, coordinated several project functions, and held design responsibility from tender to field acceptance.
